MikroTik CCR2004-16G-2S+ Cloud Core Router in Kenya

The MikroTik CCR2004-16G-2S+ is a high-performance Cloud Core Router designed for demanding business, enterprise and ISP networks. It combines 16 Gigabit Ethernet ports, two 10G SFP+ cages, a quad-core 64-bit ARM processor, 4GB of DDR4 RAM and RouterOS v7 in a standard 1U rackmount enclosure.

MikroTik built the CCR2004-16G-2S+ around the Annapurna Labs AL32400 processor, with four ARMv8-A Cortex-A57 cores running at 1.7GHz. MikroTik particularly emphasizes the model's strong single-core performance, which is useful for RouterOS operations that depend heavily on per-connection processing, including queues and other CPU-intensive workloads.

The router is suitable for ISP edge routing, large office gateways, multi-WAN systems, fibre networks, Starlink backup, VLAN routing, VPNs, BGP, OSPF, hotspot infrastructure and server-room aggregation. Dual redundant AC power supplies and active cooling further make it appropriate for rack-based business infrastructure where uptime matters.

MikroTik CCR2004-16G-2S+ Key Features

16 Gigabit Ethernet Ports

The CCR2004-16G-2S+ provides 16 independent 10/100/1000Mbps Ethernet ports.

This unusually high Ethernet port count allows the router to connect directly to:

• Access switches

• Servers

• ISP uplinks

• CCTV networks

• Wireless controllers

• Office LANs

• VLAN trunks

• Management networks

• Customer-facing networks

For many businesses, the 16 ports can reduce the immediate need for an additional access switch at the routing layer.

A typical layout could be:

ether1 – Fibre ISP
ether2 – Starlink backup
ether3–8 – Network segments
ether9–16 – Switches / servers / infrastructure

The exact configuration can be customized through RouterOS.

Dual 10G SFP+ Interfaces

The router includes two 10Gbps SFP+ cages.

These high-speed interfaces are particularly useful for:

• 10G fibre uplinks

• 10G switch connections

• ISP upstream links

• Core network connections

• Server-room aggregation

• High-speed downstream switching

A common business architecture is:

10G ISP / Core Switch → SFP+ 1 → CCR2004 → SFP+ 2 → Distribution Switch

while the 16 Gigabit ports serve local networks and lower-speed devices.

Independent High-Bandwidth Port Architecture

One of the most important design features of the CCR2004-16G-2S+ is how the interfaces connect internally.

MikroTik states that each group of eight Gigabit Ethernet ports is connected to a separate Marvell Amethyst switch chip, with each switch chip connected to the CPU by a 10Gbps full-duplex link. Each SFP+ cage also has its own separate 10Gbps full-duplex connection to the CPU.

This means the device is not designed around a single narrow internal uplink shared by all 18 network interfaces.

The practical performance still depends on:

• RouterOS configuration

• Firewall rules

• Queues

• NAT

• Packet sizes

• VPN encryption

• Routing protocols

• Traffic patterns

but the internal architecture gives the router substantial bandwidth for demanding deployments.

Quad-Core 1.7GHz ARM64 CPU

The CCR2004-16G-2S+ uses the AL32400, an Annapurna Labs Alpine v2 64-bit ARM processor.

Its specifications include:

MikroTik specifically highlights the router's single-core performance because some networking operations are difficult to spread evenly across many CPU cores.

This makes the CCR2004 particularly useful for configurations involving:

• Queues

• Firewall rules

• NAT

• VPN

• Routing policies

• BGP

• OSPF

• Inter-VLAN routing

4GB DDR4 RAM

The CCR2004-16G-2S+ contains 4GB of DDR4 RAM and 128MB NAND storage.

The 4GB memory capacity is significantly higher than what is found in most entry-level MikroTik routers and supports more demanding routing environments.

This can be useful for:

• Large routing tables

• BGP

• Many active connections

• Large firewall rule sets

• VPN deployments

• Multiple VLANs

• Complex RouterOS configurations

• Network monitoring

RouterOS v7

The CCR2004-16G-2S+ runs RouterOS v7 and carries a Level 6 licence.

RouterOS can provide advanced functions including:

• Static routing

• BGP

• OSPF

• IPv6

• NAT

• Firewall

• VLANs

• DHCP

• PPPoE

• VPN

• QoS

• Queues

• Policy routing

• Hotspot

• Multi-WAN

• Monitoring

• SNMP

• Scripting

MikroTik's current quick guide also advises keeping the router upgraded to the latest applicable RouterOS version for regulatory compliance, security and stability.

MikroTik CCR2004 for ISP Networks

The CCR2004-16G-2S+ is particularly well suited to small and medium ISP networks that require more routing capacity than conventional RouterBOARD devices.

Potential ISP applications include:

• Internet edge routing

• BGP

• PPPoE aggregation

• Customer VLAN routing

• CGNAT designs

• Traffic shaping

• Multiple upstream providers

• ISP failover

• Network aggregation

• Wireless ISP infrastructure

A typical ISP topology could be:

Upstream ISP / Transit
↓
10G SFP+
↓
CCR2004-16G-2S+
↓
Distribution Switches
↓
Customers / Towers / Access Networks

The exact supported subscriber count cannot be defined from hardware specifications alone because it depends heavily on traffic patterns and RouterOS configuration.

MikroTik CCR2004 for Business Networks

The CCR2004 is also an excellent central gateway for larger companies.

A business could use the 16 Gigabit ports to connect:

• Managed switches

• Office networks

• Servers

• CCTV

• VoIP

• Wi-Fi infrastructure

• Guest networks

• Building links

while the two 10G SFP+ ports provide high-speed uplinks.

For example:

Fibre + Starlink → CCR2004 → 10G Core Switch → Office Network

This provides a central platform for controlling WAN connectivity, VLANs, firewalling, bandwidth and VPN access.

MikroTik CCR2004 for Fibre Internet

The CCR2004 can be used as a powerful fibre gateway where the provider presents the service through:

• Ethernet

• SFP

• SFP+

• DHCP

• Static IP

• PPPoE

depending on the ISP's architecture.

Typical topology:

Fibre ISP → CCR2004 → Core Switch → Access Switches → Users

Its dual 10G SFP+ ports mean it can also be used where the business has moved beyond standard 1Gbps networking.

MikroTik CCR2004 for Starlink

The CCR2004 can integrate Starlink into a larger business network.

A typical design is:

Starlink → Ethernet → CCR2004

The CCR2004 can then manage:

• NAT

• Firewall

• VLANs

• Guest Wi-Fi

• Staff network

• CCTV

• VPN

• Traffic shaping

• Failover

For a small single-site Starlink setup, a CCR2004 would usually be excessive.

Its value becomes clearer when Starlink is part of a larger enterprise network, particularly when combined with fibre or another ISP.

Fibre + Starlink Multi-WAN

A strong use case is combining fibre and Starlink.

Example:

WAN 1: Fibre
WAN 2: Starlink
↓
CCR2004-16G-2S+
↓
Enterprise LAN

RouterOS can be configured for:

Automatic Failover

Fibre operates as the primary connection and Starlink becomes active if fibre fails.

Policy-Based Routing

Certain departments or VLANs can be routed through different internet connections.

Load Distribution

Different network sessions can be distributed across multiple WAN connections.

Load balancing should not be confused with true link bonding. Two 500Mbps WANs do not automatically give a single user a 1Gbps download.

MikroTik CCR2004 for VLAN Routing

The CCR2004 can serve as an inter-VLAN gateway.

For example:

The CCR2004 can route between these VLANs while applying firewall rules that determine which networks are allowed to communicate.

For example:

Guest VLAN → Internet only

CCTV VLAN → NVR only

Staff VLAN → Servers + Internet

Management VLAN → Full infrastructure access

This is considerably more secure and manageable than placing every device on one flat network.

MikroTik CCR2004 for CCTV Networks

The router can also serve as the gateway for large CCTV deployments.

A structured layout might be:

CCTV Cameras → PoE Switches → VLAN 40 → Core Switch → CCR2004

The MikroTik can then control:

• Remote NVR access

• Internet access

• VPN access

• Camera VLAN isolation

• Bandwidth policies

• Routing between multiple locations

The actual video traffic between cameras and a local NVR may remain inside the switching infrastructure, avoiding unnecessary routing through the CCR.

MikroTik CCR2004 as a VPN Gateway

The CCR2004 can be deployed as a centralized VPN router.

Potential applications include:

Head Office ↔ Branch Office

Remote Employee ↔ Office

Office ↔ Cloud Infrastructure

Office ↔ Data Centre

Multiple Branches ↔ Headquarters

MikroTik's official performance testing includes configurations with 256 AES-256 tunnels, demonstrating that the manufacturer tests the platform for substantial encrypted-routing workloads. Actual VPN performance varies significantly with protocol, encryption, packet sizes and configuration.

MikroTik CCR2004 for BGP

BGP is one of the most important applications for Cloud Core Routers.

The CCR2004 can be suitable for organisations that:

• Operate an ASN

• Connect to multiple upstream ISPs

• Exchange routes

• Manage ISP networks

• Need dynamic routing

Its 4GB RAM and ARM64 CPU give it substantially more resources than entry-level MikroTik routers.

For extremely large-scale BGP and high-throughput core routing, higher-end CCR models such as the CCR2116 or CCR2216 may be more appropriate.

MikroTik CCR2004 for OSPF

OSPF can be used to exchange routes dynamically between routers within a company or ISP network.

For example:

Head Office CCR2004
↕
Branch Router
↕
Remote Site Router

Rather than configuring every route manually, OSPF can dynamically distribute network information.

This becomes useful in:

• Campus networks

• ISPs

• Multi-building sites

• Large hotels

• Universities

• Multi-branch organizations

Dual Redundant Power Supplies

The CCR2004-16G-2S+ includes two built-in AC power supplies.

Specifications include:

Dual power inputs are valuable in business and ISP environments because each PSU can potentially be connected to a different power source or UPS.

For example:

PSU 1 → UPS A

PSU 2 → UPS B / alternate power circuit

This can improve resilience against individual PSU or power-feed failures.

Active Cooling

The CCR2004-16G-2S+ uses two cooling fans.

This is an important difference between this model and the CCR2004-16G-2S+PC, which uses a passively cooled design.

Active cooling allows the 1.7GHz CCR2004 to maintain performance in demanding rack environments, although it means the router is better suited to:

• Server rooms

• Network cabinets

• Data rooms

• ISP racks

than to a quiet desk or home office.

1U Rackmount Design

The CCR2004 measures approximately:

443 × 210 × 44mm.

Its 44mm height corresponds to a standard 1U rackmount form factor.

It is therefore suitable for:

• 19-inch server racks

• Network cabinets

• ISP racks

• Data rooms

• Enterprise server rooms

MikroTik's documentation specifically states that the unit is intended for rackmount installation and indoor operation.

USB Port

The CCR2004-16G-2S+ includes one USB port.

Depending on RouterOS support and intended application, USB can be useful for compatible peripherals or storage-related functions.

The router also includes an RJ45 serial console port, which provides an alternative management method for administrators.

CCR2004 Performance

MikroTik publishes RFC2544 performance testing for the CCR2004 platform.

For large 1518-byte packets, official laboratory testing reports fast-path routing results exceeding 35Gbps, while performance falls as packet sizes shrink or additional processing such as filters or encryption is introduced.

This is a useful reminder that there is no single universal "CCR2004 throughput" figure.

Performance depends on:

• Packet size

• Firewall rules

• Bridge filtering

• NAT

• Queues

• VPN

• Routing protocols

• FastPath/FastTrack

• RouterOS version

• Number of connections

MikroTik itself notes that its benchmark results represent test configurations and that different real-world configurations are likely to produce lower performance.

CCR2004-16G-2S+ vs CCR2004-16G-2S+PC

These two models have similar port layouts but important differences.

The CCR2004-16G-2S+ prioritizes maximum CPU speed and redundant rack infrastructure.

The CCR2004-16G-2S+PC prioritizes quiet operation.

CCR2004 vs RB5009

The RB5009 is excellent for smaller networks and offers a useful 2.5GbE interface.

The CCR2004 is better suited to users requiring more Ethernet ports, dual 10G interfaces, more RAM, redundant AC power and rackmount enterprise deployment.

CCR2004 vs CCR2116

The CCR2116 is considerably more powerful, but it can also be excessive where the CCR2004 already meets the required traffic and routing workload.

Advantages of MikroTik CCR2004-16G-2S+

Key advantages include:

• 16 Gigabit Ethernet ports

• Two 10G SFP+ ports

• Powerful 1.7GHz ARM64 CPU

• 4GB DDR4 RAM

• RouterOS v7

• Level 6 licence

• Dual redundant AC power supplies

• Active cooling

• Standard 1U rackmount design

• USB

• Serial console

• VLAN routing

• BGP

• OSPF

• VPN

• Multi-WAN

• Strong price-to-performance ratio for enterprise routing

Limitations to Consider

The CCR2004 is powerful, but customers should understand several limitations:

• It has no built-in Wi-Fi

• It has no dedicated 2.5GbE copper port

• 10G requires suitable SFP+ modules or DACs

• Active cooling produces fan noise

• It requires proper RouterOS configuration

• Advanced BGP/VPN/firewall designs require networking expertise

• It is usually excessive for small homes

• Switches may still be required for large access networks

• SFP/SFP+ compatibility should be checked before purchase

For Wi-Fi coverage, pair the router with dedicated wireless access points.

Who Should Buy the CCR2004-16G-2S+?

The CCR2004 makes particular sense for:

Internet Service Providers

For BGP, aggregation, PPPoE, multi-WAN and traffic management.

Medium and Large Businesses

For centralized routing, VLANs, VPN and multi-gigabit uplinks.

Hotels

For guest Wi-Fi, management, CCTV, VoIP and multiple VLANs.

Universities and Schools

For multi-building network routing and internet gateway applications.

Data and Server Rooms

For high-speed rack-based network aggregation.

Multi-Site Companies

For site-to-site VPN and dynamic routing.

Starlink + Fibre Businesses

For resilient dual-WAN networking.

Typical CCR2004 Enterprise Network

A professional deployment could look like:

Fibre ISP 1
Fibre ISP 2
Starlink Backup
↓
MikroTik CCR2004-16G-2S+
↓
10G Core Switch
↓
Managed Access Switches
↓
Wi-Fi APs / CCTV / Servers / PCs / VoIP

VLANs could then separate the various services while the CCR2004 performs routing and security at the core.

MikroTik CCR2004-16G-2S+ Price in Kenya

The MikroTik CCR2004-16G-2S+ price in Kenya varies according to stock, import costs, supplier and exchange rates.

MikroTik currently lists a manufacturer suggested price of US$465, but that is not an Orbitlink Solutions Kenya retail quotation and does not account for freight, taxes, local distribution or other costs.

For Orbitlink Solutions:

Contact Orbitlink Solutions for the current CCR2004-16G-2S+ price and stock availability.

A complete deployment may additionally require:

• SFP+ transceivers

• Fibre patch cords

• DAC cables

• Managed switches

• Rack cabinet

• UPS

• Patch panels

• Ethernet cabling

• Configuration

• Installation

Why Buy MikroTik CCR2004-16G-2S+ from Orbitlink Solutions?

Orbitlink Solutions can help customers determine whether the CCR2004 is appropriate for their actual network requirements rather than simply selecting it because it is a Cloud Core Router.

The correct model should depend on:

• Internet capacity

• Number of users

• VLAN count

• WAN connections

• VPN requirements

• BGP/OSPF needs

• SFP+ requirements

• Future network expansion

For smaller installations, an RB5009 may provide better value. For much heavier ISP or data-centre routing, the CCR2116 or CCR2216 may be more appropriate.

Watch the MikroTik CCR2004-16G-2S+ Video

The CCR2004-16G-2S+ occupies an important position in MikroTik's routing range because it combines a large number of conventional Gigabit ports with genuine 10G uplinks. This can make it particularly attractive to organisations that still have many Gigabit endpoints but need to aggregate those connections into faster core infrastructure.

Its 4GB of DDR4 memory, RouterOS Level 6 licence and ARM64 processor also make it substantially more capable than ordinary small-office routers. It can serve as a firewall, multi-WAN gateway, inter-VLAN router, VPN platform or dynamic-routing device without requiring separate appliances for every function.

The router should nevertheless be selected according to workload rather than headline port count. A configuration with heavy queues, extensive firewall rules, hundreds of VPN tunnels or complex BGP policy may perform very differently from simple fast-path routing. MikroTik publishes several performance tests precisely because actual throughput varies substantially with the type of packet processing being performed.

Frequently Asked Questions About MikroTik CCR2004-16G-2S+

What is the MikroTik CCR2004-16G-2S+?

It is a rackmount MikroTik Cloud Core Router designed for enterprise and ISP networking, with 16 Gigabit Ethernet ports and two 10G SFP+ cages.

How many Ethernet ports does CCR2004-16G-2S+ have?

It has 16 Gigabit Ethernet ports.

How many 10G ports does it have?

It has two SFP+ cages capable of 10Gbps connectivity.

What CPU does the CCR2004 use?

It uses an AL32400 ARM64 quad-core processor running at 1.7GHz.

How much RAM does CCR2004 have?

It has 4GB DDR4 RAM.

What storage does it have?

It has 128MB NAND storage.

Does CCR2004 run RouterOS v7?

Yes. The current official specification lists RouterOS v7.

What RouterOS licence does CCR2004 have?

It has a Level 6 licence.

Does CCR2004 have Wi-Fi?

No. It is a wired enterprise router. Dedicated access points should be used for Wi-Fi.

Does CCR2004 support fibre?

Yes. Its two SFP+ cages can accept compatible fibre transceivers.

Can CCR2004 work with Starlink?

Yes. It can be used as the main enterprise gateway behind Starlink.

Can CCR2004 use Starlink and fibre together?

Yes. RouterOS can be configured for multi-WAN, automatic failover or policy-based routing.

Can CCR2004 handle VLANs?

Yes. It can perform VLAN routing and apply firewall policies between VLANs.

Does CCR2004 support BGP?

Yes. RouterOS v7 supports BGP and the CCR series is widely suited to dynamic routing environments.

Does CCR2004 support OSPF?

Yes. RouterOS supports OSPF.

Can CCR2004 run VPNs?

Yes. It can be configured as a VPN gateway, with practical encrypted throughput depending on protocol and configuration.

Does it have redundant power supplies?

Yes. The CCR2004-16G-2S+ includes two built-in AC power supplies.

Is the CCR2004 fanless?

No. The CCR2004-16G-2S+ uses active cooling with two fans.

Is there a fanless version?

Yes. MikroTik also offers the CCR2004-16G-2S+PC, which uses passive cooling and operates its CPU at a lower 1.2GHz frequency.

Is CCR2004 rackmountable?

Yes. It uses a standard 1U rackmount enclosure measuring about 443 × 210 × 44mm.

Is CCR2004 suitable for an ISP?

Yes. It is suitable for many small and medium ISP, WISP and enterprise routing applications.

Is CCR2004 better than RB5009?

It is a higher-class device for networks requiring more Ethernet ports, two 10G links, 4GB RAM, redundant power and rackmount deployment. RB5009 can be more economical for smaller networks.

Is CCR2116 more powerful than CCR2004?

Yes. CCR2116 offers substantially more CPU cores, memory and 10G interfaces and targets heavier ISP and core-routing workloads.

What is the CCR2004-16G-2S+ price in Kenya?

Contact Orbitlink Solutions for the current exact-model price and stock availability.

Buy MikroTik CCR2004-16G-2S+ in Kenya

The MikroTik CCR2004-16G-2S+ is a strong choice for organisations that need more than a conventional Gigabit gateway. Its combination of 16 Gigabit Ethernet ports, two 10G SFP+ interfaces, 4GB DDR4 RAM, a 1.7GHz quad-core ARM64 CPU, redundant AC power and RouterOS v7 makes it suitable for demanding enterprise and ISP networks.

It is particularly well suited to multi-WAN, fibre, Starlink backup, BGP, VLAN routing, VPN, hotspot, server-room and network aggregation applications where high availability and substantial routing capacity are required.

Contact Orbitlink Solutions

Orbitlink Solutions
Lyric House, 7th Floor, Room S9, Kimathi Street, Nairobi
Call / Text / WhatsApp: +254 743 720 551
Email: info@orbitlinksolutions.co.ke
Alternative Email: orbitlinksolutions@gmail.com
Opening Hours: Monday–Saturday, 9:00 AM–6:00 PM
Availability: Nairobi pickup and nationwide delivery

Contact Orbitlink Solutions for the current MikroTik CCR2004-16G-2S+ price in Kenya, stock availability, SFP+ selection, configuration and deployment guidance for enterprise, ISP, fibre and Starlink networks.
